    Electronic Component 22213e/Ek Spherical Roller Thrust Bearing For Rolling Mill

    Ask Lasest Price
    Brand Name : SFT
    Model Number : 22213e/ek
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 50000PCS/MONTH
    Delivery Time : 20-45DAYS
    • Product Details
    • Company Profile

    Electronic Component 22213e/Ek Spherical Roller Thrust Bearing For Rolling Mill

    Electronic Component 22213e/ek thrust spherical roller bearing


    spherical roller bearings features:

    • 1.Increase Load Rating
    • 2.Longer Operating Life
    • 3.Low Noise
    • 4.High Temperature Lasting (up to 200 Celsius)
    • 5.Suitable for application where misalignment can arise from error in mounting or from shaft deflection.
    • 6.Extremely high radial load capability because of the line contact to the rollers and raceway.
    • 7.Wide array of product line : from ID 25mm , 0ver OD 1000mm
    • 8.Easy mounting and dismounting by tapered bore
    • 9.Press fitting adapter sleeves make internal clearance adjustment.

    spherical roller bearings application:


    1.papermaking machinery, deceleration device, railway vehicle axle, rolling mill, roller gearbox,crusher,

    vibrating screen, printing machinery, woodworking machinery, various industrial reducer,

    vertical insert self-aligning bearing

    2.Spherical Roller Bearings are suitable for the high axial , impulse and heavy load applications

    such as paper manufacturing, rolling and other large size machineries.

    Other Designs and Variants Type

    Double row spherical roller bearings

    *Most widely used.

    Single row spherical roller bearings

    *Radial load and compensation misalignment

    Split spherical roller bearings

    *Carrying out replacement work quickly and easily

    Sealed spherical roller bearings

    *Harsh environment applications

    Spherical roller bearings for vibratory machinery

    *Vibration machinery application


    Exterior Designs

    W33
    Annular groove and three lubrication holes in the outer ring
    K
    Tapered bore, taper 1:12
    K30
    Tapered bore, taper 1:30
    W20
    Three lubrication holes in the outer ring
    W26
    Six lubrication holes in the inner ring
    W
    Without annular groove and lubrication holes
    SH
    Outer ring screw holes (can be customized)
    2RS
    Contact seal, NBR, on one or both sides

    Sperical Roller bearing Related models

    model listd(mm)D(mm)B(mm)Cr( N)C0r(N)m(kg)
    2230840903373500905001.041
    2230945100361080001400001.387
    2231050110401408001700001.827
    2231155120431705001980002.299
    2231260130461848002250002.881
    2231365140482068002520003.494
    2231470150512530003150004.212
    2231575160552882003880005.225
    2231680170583168004050006.296
    2231785180603388004400007.36
    2231890190644015005420008.878
    22319952006742350057000010.38
    223201002157349500066800012.941
    223221102408059950083200017.85
    223241202608670950099200022.378
    2232613028093794200114000028.13
    22328140300102907500134000034.84
    223301503201081230000160000043.6
    223321603401141380000179000051.9
    223341703601201420000206000060.75
    223361803801261470000227000068.08
    223381904001321529000253000083.22
