GE 140 SX Steering Knuckle Bearing Joint Bearing Spherical Plain bearings

GE 140 SX Knuckle Bearing / Joint Bearing /Spherical Plain Bearing

Product Description of Spherical Plain Bearing:

Radial spherical plain bearings have an inner ring with a sphered convex outside diameter and an outer ring with a correspondingly sphered but concave inside surface. Their design makes them particularly suitable for bearing arrangements where alignment movements between shaft and housing have to be accommodated, or where oscillating or recurrent tilting or slewing movements must be possible at relatively slow sliding speeds.

Radial spherical plain bearings requiring maintenance have the sliding contact surface combination steel-on-steel. Bearings with this sliding contact surface combination require regular relubrication. The high wear resistance of the sliding surfaces makes these bearings especially suitable for bearing arrangements where heavy loads of alternating direction, shock loads or heavy static loads have to be accommodated. Bearings which have cylindrical extensions at both sides of the inner ring are intended for applications where normally spacer sleeves are arranged at either side of the bearing, or are specially designed for the bearing arrangements of hydraulic cylinders.

Features of Spherical bearing

SPECIFICATION
Model	GE 140 SX
Material	Steel / Steel
Inner diameter	140mm
Outer diameter	210mm
ball width	45mm
Model Available	GE, GEES2RS, GAC, GEC, GEG, GEZ, GEEM, GET, ......
Application	Agricultural machinery, Shock absorber, etc
Package	Tube, carton box, wooden box, pallet
Delivery time	1 day for sample, 3-5 day for medium order, 10-20 day for big order quantity
OEM	Accept
Payment terms	TT, L.C, D/A, D/P, Western Union, Paypal

GE... SX Angular Contact Spherical Plain Bearing

GE 140 SX Steering Knuckle Bearing Joint Bearing Spherical Plain bearings

Model	Shaft Diameter	Mass	Dimensions (mm)							Basic load ratings
		kg	d	D	T	dk	D1	B	C	Dyn.	Stat.
			d	D	T	dk	D1	B	C	Cr N	Cor . N
GE 25 SX	25	0.14	25	47	15	42.5	31.4	14	14	47800	239000
GE 28 SX	28	0.18	28	52	16	47	35.7	15	15	57500	287000
GE 30 SX	30	0.21	30	55	17	50	36.1	16	16	64600	323000
GE 35 SX	35	0.27	35	62	18	56	42.4	17	17	78500	392000
GE 40 SX	40	0.33	40	68	19	60	46.8	18	18	90600	453000
GE 45 SX	45	0.42	45	75	20	66	52.9	19	19	106000	532000
GE 50 SX	50	0.46	50	80	20	74	59.1	19	19	118000	590000
GE 55 SX	55	0.68	55	90	23	80	62	22	22	149000	745000
GE 60 SX	60	0.73	60	95	23	86	68.1	22	22	160000	802000
GE 65 SX	65	0.77	65	100	23	92	75.6	22	22	173000	867000
GE 70 SX	70	1.1	70	110	25	102	82.2	24	24	208000	1040000
GE 80 SX	80	1.5	80	125	29	115	90.5	27	27	244000	1220000
GE 90 SX	90	2.1	90	140	32	130	103.3	30	30	313000	1560000
GE100SX	100	2.3	100	150	32	140	114.3	30	30	339000	1690000
GE110SX	110	3.9	110	170	38	160	125.8	36	36	469000	2340000
GE120SX	120	4	120	180	38	170	135.4	36	36	498000	2490000
GE130SX	130	6.1	130	200	45	190	148	42	42	622000	3110000
GE140SX	140	6.5	140	210	45	200	160.6	42	42	663000	3310000
GE150SX	150	7.9	150	225	48	213	170.9	45	45	764000	3820000
GE160SX	160	9.4	160	240	51	225	181.4	48	48	872000	4360000
GE170SX	170	13	170	260	57	250	194.3	54	54	1080000	5440000
GE180SX	180	17.5	180	280	64	260	205.5	61	61	1310000	6590000
GE190SX	190	18.3	190	290	64	275	211.8	61	61	1370000	6850000
GE200SX	200	23.3	200	310	70	290	229.2	66	66	1540000	7740000

Applications of Spherical Plain Bearing:

electric motors, automotive applications, home appliances, industrial equipment.

Radial Spherical plain bearings are design to cater to all heavy loading equipments.

Plain bearings are able to cater to various sliding contact surfaces;

Steel/PTFE composite material and Steel/PTFE fabric material.

Range of production range from ID15mm to ID250mm.
